Pipe clamp

Pipe clamp

Material: steel galvanized
Working temperature: -300 to 900
Product features: durable, high and low temperature resistance

Purpose: Used for fastening and anti-vibration of pipeline systems such as water supply and drainage,

 heating and ventilation. Need to pass through the bolt column at both ends during the installation process,

Installed on the pipeline engineering has the effect of tightening and fixing; it can also be used with anti-seismic

accessories through welding or bolt-column connection, and has the effect of anti-seismic fastening.

Application areas: It can be used in the automotive industry, rail transit, photovoltaic industry, engineering construction,

 electric power, metallurgy and chemical industry, bridge manufacturing and other industries.

Specification

product name Product number Inside diameter(mm thickness
(mm)
unit package
O type pipe clamp GKO-65 65 5 set 1
GKO-80 80
GKO-100 100
GKO-125 125
GKO-150 150
GKO-200 200
Ohm tube card GKR-65 65
GKR-80 80
GKR-100 100
GKR-125 125
GKR-150 150
GKR-200 200
U type pipe clamp GKU-65 65
GKU-80 80
GKU-100 100
GKU-125 125
GKU-150 150
GKU-200 200
