Material：UL approved NYLON66
Fireproof: 94V-2
| Item No. |
Mounting Hole A(mm) |
Max. cable range B(mm) |
Covering C(mm) |
Height L(mm) |
Packing | |
| Black | White | |||||
| OSB-10 | OSB-10W | 9.0 | 6.0 | 11.8 | 9.8 | 100pcs |
| OSB-13 | OSB-13W | 12.5 | 7.5 | 15.1 | 10.3 | |
| OSB-16 | OSB-16W | 15.5 | 11.2 | 18.5 | 10.3 | |
| OSB-19 | OSB-19W | 18.4 | 12.5 | 21.0 | 10.3 | |
| OSB-22 | OSB-22W | 22.0 | 17.0 | 24.6 | 10.3 | |
| OSB-26 | OSB-26W | 25.5 | 20.0 | 28.4 | 10.6 | |
