Cable connector,cable waterproof connector

Item No.		Thread	CableRange Φ	Thread O.D. D1	Panel Mounting Hole	Thread Length L1	Joint Length L2+L3	Spanner size A&F
Black	White	Thread	CableRange Φ	Thread O.D. D1	Panel Mounting Hole	Thread Length L1	Joint Length L2+L3	Spanner size A&F
MG12A-05B	MG12A-05G	M12*1.5	3-5.3	12	12-12.3	8.5	38	18/19
*MG12A-08B	MG12A-08G	M12*1.5	4-8	12	12-12.3	8.5	30	18/19
MG16A-07B	MG16A-07G	M16*1.5	4-7	16	16-16.3	15	35	22/22
*MG16A-10B	MG16A-10G	M16*1.5	6-10	16	16-16.3	15	35	22/22
MG20A-06B	MG20A-06G	M20*1.5	4-6	20	20-20.3	15	37	27/27
MG20A-11B	MG20A-11G	M20*1.5	6-11	20	20-20.3	15	37	27/27
*MG20A-14B	MG20A-14G	M20*1.5	9-14	20	20-20.3	15	42	27/27
MG25A-16B	MG25A-16G	M25*1.5	10-16	25	25-25.3	15	42	33/33
*MG25A-18B	MG25A-18G	M25*1.5	13-18	25	25-25.3	15	48	33/33
MG32A-22B	MG32A-22G	M32*1.5	15-22	32	32-32.3	15	48	41/42
*MG32A-25B	MG32A-25G	M32*1.5	18-25	32	32-32.3	15	51	41/42
MG40A-25B	MG40A-25G	M40*1.5	20-26	40	40-40.3	20	51	50/52
*MG40A-30B	MG40A-30G	M40*1.5	24-31	40	40-40.3	20	59	50/52
MG50A-32B	MG50A-32G	M50*1.5	25-33	50	50-50.3	22	59	62/62
*MG50A-40B	MG50A-40G	M50*1.5	30-41	50	50-50.3	22	65	62/62
MG63A-46B	MG63A-46G	M63*1.5	39-46	63	63-63.3	25	65	75/75
*MG63A-50B	MG63A-50G	M63*1.5	40-51	63	63-63.3	25	65	75/75
MG75A-56B	MG75A-56G	M75*2.0	50-56	75	75-75.3	25	65	92/92
MG75A-66B	MG75A-66G	M75*2.0	55-66	75	75-75.3	25	65	92/92
MG90A-68B	MG90A-68G	M90*2.0	58-68	90	90-90.3	25	65	110/110
MG90A-77B	MG90A-77G	M90*2.0	65-77	90	90-90.3	25	65	110/110
MG16AS-05BST	MG16AS-05GST	M16*1.5	3-5.5	16	16-16.3	10	30	22/19
MG16AS-08BST	MG16AS-08GST	M16*1.5	4-8	16	16-16.3	10	30	22/19
MG16AS-05B	MG16AS-05G	M16*1.5	3-5.5	16	16-16.3	10	35	22/19
MG16AS-08B	MG16AS-08G	M16*1.5	4-8	16	16-16.3	10	35	22/19
MG16A-07BST	MG16A-07GST	M16*1.5	4-7	16	16-16.3	10	35	22/22
MG16A-10BST	MG16A-10GST	M16*1.5	6-10	16	16-16.3	10	35	22/22
MG20AS-09BST	MG20AS-09GST	M20*1.5	5-9	20	20-20.3	10	37	24/24
MG20AS-12BST	MG20AS-12GST	M20*1.5	6-12.5	20	20-20.3	10	37	24/24
MG20A-11BST	MG20A-11GST	M20*1.5	6-11	20	20-20.3	10	37	27/27
MG20A-14BST	MG20A-14GST	M20*1.5	9-14	20	20-20.3	10	37	27/27
MG25AS-11BST	MG25AS-11GST	M25*1.5	6-11	25	25-25.3	10	42	33/27
MG25AS-14BST	MG25AS-14GST	M25*1.5	9-14	25	25-25.3	10	42	33/27
MG25AS-16BST	MG25AS-16GST	M25*1.5	10-16	25	25-25.3	10	42	33/33
MG25AS-18BST	MG25AS-18GST	M25*1.5	13-18	25	25-25.3	10	42	33/33
